Noise Dosimeter SV 104 Product Page

Noise Dosimeters > SV 104

Noise Dosimeter SV 104

5.0 (20 Reviews)

The SV 104 is a compact, body-worn Personal Sound Exposure Meter (PSEM) designed for full-shift, near-ear noise monitoring in industrial and field environments. It complies with IEC 61252:2017 and ANSI/ASA S1.25-1991 (R2020) standards for personal noise dosimeters and when used with compatible accessories meets IEC 61672-1:2013 Class 2 requirements for integrating-averaging sound level meters. Engineered for hearing conservation and occupational compliance, the SV 104 continuously measures sound pressure levels to calculate Dose (%), TWA8h, and LEX,8h / LEP,d in accordance with OSHA, MSHA, ACGIH, and ISO 9612 guidelines. It records A-weighted SPL and supports three independent measurement profiles ... simultaneously, allowing flexible setup across 2/3/4/5/6 dB exchange rates and Fast/Slow/Impulse time constants within a 55–140 dB(A) range. A patented ½″ MEMS microphone with a lifetime warranty ensures long-term accuracy and easy field calibration. The SV 104 comes fully equipped with all essential accessories and is also available in two specialized variants SV 104IS for intrinsically safe operation in hazardous environments and SV 104A with Bluetooth® connectivity for real-time monitoring via a mobile app.

Inquire Now

The SV 104 is a compact personal noise dosimeter designed for accurate and reliable occupational noise exposure monitoring in everyday workplace environments. Built for ease of use and consistency, it combines automated calibration, self-vibration detection, and stable MEMS microphone technology to ensure dependable measurements throughout a work shift.

Designed to support compliance with international noise standards, the SV 104 simplifies noise dosimetry through intelligent data logging, long operating time, and a lightweight, wearable form factor. Its robust design and automated functions make it an ideal solution for routine occupational noise assessments where accuracy, repeatability, and efficiency are critical.

Sound measurements features
Sound measurements	✔️
Occupational noise	✔️
Number of channels	1
Intrinsic safety	-
Self-vibration detection	✔️
Auto-calibration	✔️
Keyboard lock	✔️
Remote communication	-
Bluetooth	-
Communication interfaces	USB, infrared
LED indicator	✔️
Display	✔️
Keyboard	3 push buttons
Memory	8 GB
Battery type	Ni-MH rechargeable cells
Operating time	40 hours
Operating temperature range	-10 °C ÷ +50 °C
Humidity range	up to 95 % RH
Weight	121 g
Size	88 × 49.5 × 19.2 mm
Docking station required	-
Standards	IEC 61252 Ed.1.2 (R2017); ANSI S1.25-1991 (R2020)
Microphone type	ST 104C MEMS microphone
Linear operating range to IEC 61672	55 dBA RMS ÷ 140.1 dBA Peak
Total measurement range	50 dBA RMS ÷ 140.1 dBA Peak
Frequency range	20 Hz ÷ 10 kHz
Weighting filters	A, C and Z
Time constants	Slow, Fast, Impulse
Exchange rates	2, 3, 4, 5, 6
Criterion levels	Selectable
Profiles per channel	3 with independent filters (x) and time constants (y)
Min logging step	1 s logger step
Statistics in octaves or third octaves	✔️
Audio recording	Option
Voice comments	✔️
1/1 octave	Option

Other Features & Highlights

Compliance-ready: Fully supports OSHA 29 CFR 1910.95, MSHA, ACGIH, and ISO 9612 measurement profiles for regulatory validation.
Certified standards: Meets IEC 61252:2017 and ANSI/ASA S1.25-1991 (R2020); with listed accessories, complies with IEC 61672-1:2013 Class 2.
Parallel profiles: Operate up to three independent profiles simultaneously, each with different exchange rates and time constants.
Detailed A-weighted logging: Records dual-step time-history of Leq, Max, Min, and Peak values for complete traceability.
Patented MEMS microphone: Lifetime warranty, shock-resistant design, ensuring long-term stability and quick field calibration.
Vibration detection: Built-in triaxial sensor automatically flags shocks or mishandling events, maintaining data accuracy.
Readable OLED display: High-contrast screen ensures clear visibility in both bright and low-light conditions.
Extended operation: Delivers over 40 hours of battery life (profile-dependent), ideal for full-shift measurements.
Integrated ecosystem: Supplied with PC software and mobile app, with free firmware upgrades for enhanced usability.
Optional analytics: Expand capabilities with 1/1- and 1/3-octave analysis or audio recording—perpetual license, no expiry.
Comprehensive warranty: Includes 36-month instrument coverage plus extended microphone protection.
Specialized variants: Available as SV 104IS (intrinsically safe) for hazardous zones and SV 104A (Bluetooth-enabled).
Fleet bundle option: 5-Pack Team Kit includes 5 dosimeters, a Class 1 calibrator, multi-bay USB charging hub, and carrying case.

Downloads

Data Sheet
PDF

User Manual
PDF

Applications

Occupational Noise

Personal noise monitoring compliant with IEC 61252 and ANSI S1.25-1991 standards

The SV 104 is used for full-shift personal noise exposure assessments, ideal for environments where noise varies throughout the day such as manufacturing, construction, mining, logistics, and utilities. It supports task-based studies, baseline surveys, and post-change evaluations, ensuring existing hearing protection remains effective. Measurement results meet ISO 9612 and OSHA 1910.95 compliance requirements, providing reliable data for OSHA/NIOSH reporting, and supporting the proper selection of hearing protectors and administrative noise control measures.

Inteccon - Features

Key Features

The SV 104 is a reliable personal noise dosimeter designed for accurate occupational noise monitoring. Its robust design and automated features support consistent measurements in everyday workplace conditions.

MEMS Microphone Technology

Stable and Consistent Sound Measurement. ST 104C MEMS microphone delivers reliable noise measurements with long-term stability and resistance to handling stress.

Auto-Calibration

Automatic and User-Independent Accuracy. Auto-calibration detects calibration signals automatically, ensuring consistent and repeatable measurements without manual input.

Self-Vibration Detection

Built-in self-vibration detection identifies motion-related disturbances to help maintain accurate noise exposure data.

Occupational Noise Compliance

Designed for Workplace Noise Monitoring. Optimised for occupational noise and sound measurements in compliance with IEC and ANSI noise dosimetry standards.

Extended Operating Time

Reliable Full-Shift Monitoring. Provides over 40 hours of operating time on rechargeable Ni-MH batteries for uninterrupted noise measurements.

Compact & Robust Design

Built for Daily Industrial Use. Compact, lightweight design with IP-rated durability supports reliable use in demanding workplace environments.

FAQ Component

Frequently asked questions

What is a noise dosimeter?

A noise dosimeter is a small device worn near the ear that measures how much noise a person is exposed to during a work shift.

Why should I use a noise dosimeter?

It automatically records noise exposure over time, saving you from manual calculations and tracking in noisy or hard-to-access areas.

Who needs a noise dosimeter?

Workers in loud environments such as factories, construction sites, and mines use dosimeters to prevent hearing loss and ensure safety compliance.

How is a noise dosimeter different from a sound level meter?

A dosimeter is worn on the body for personal noise exposure, while a sound level meter is hand-held and measures noise in a specific area.

How do I know if the dosimeter is working properly?

Check that the screen or indicator light is on and the microphone is securely connected before starting measurement.

How is a dosimeter calibrated?

Calibration is the process of checking a dosimeter’s accuracy by comparing its response to a known reference standard. This standard must be traceable to and consistent with a national standard, ensuring that the dosimeter provides reliable and accurate measurements.

What standards does the SV 104 comply with?

It meets IEC 61252:2017 and ANSI S1.25-1991 (R2020) for personal noise dosimeters, and (with accessories) meets IEC 61672-1:2013 Class 2.

Can it run multiple measurement profiles at once?

Yes, the SV 104 supports three independent profiles in parallel, each with its own exchange rate and time weighting settings.

How long does the battery last?

Under typical use, it provides over 40 hours of operation (with display off and octave analysis off) on a full charge.

Does the SV 104 detect misuse or shocks during measurement?

Yes, it has a built-in tri-axial accelerometer (vibration sensor) which logs shock or handling events and flags them in the time history for exclusion from dose calculations
